Gas well intelligent automatic bubble row ball device, mainly used in flooded wells to resume production, low-yield wells to increase production and other fields, and carried out related product experiments and research. When the device is used for the re-production of flooded wells, 5000 high-density bubble balls can be quickly put into the gas well within 14min. After 20 minutes, the bubble balls begin to react with the bottom-hole fluid to produce a large amount of foam, which will be carried to the ground from the bottom of the well along with the airflow, thus discharging the fluid in the wellbore and achieving the purpose of drainage and gas production.
The intelligent automatic bubble row ball throwing device for gas wells can realize the remote control of bubble volleyball and automatic quantitative filling of 10-50 bubble volleyball balls (0.6Kg -3Kg) when it is used to increase production in low-yield wells, with a maximum ball storage capacity of 5000 balls, and the dosing period can be extended to more than 100 days, thus greatly reducing labor cost and labor intensity.
